CSDS-1J100_CSDS-1J101
Basic information
1.Single digit display .
2.1.8 Inch.
3.Case mold type.
4.Low power consumption.
5.Various color.
2.1.8 Inch.
3.Case mold type.
4.Low power consumption.
5.Various color.
Featured Benefits
Product specifications
Package | Outer Dimensions (mm) | Color | Part Number | Dominant Wavelength λd (nm) | Luminous Intensity IV (mcd) | Forward Current IF (mA) | ||
---|---|---|---|---|---|---|---|---|
Common Anode | Common Cathode | Min. | Typ. | |||||
1.80 inch | 38*56*11 | Green | CSDS-1J1002 | CSDS-1J1012 | 525 | 600 | 1200 | 10 |
1.80 inch | 38*56*11 | Green | CSDS-1J100M | CSDS-1J101M | 570 | 25 | 70 | 10 |
1.80 inch | 38*56*11 | Yellow | CSDS-1J100T | CSDS-1J101T | 590 | 100 | 180 | 10 |
1.80 inch | 38*56*11 | Orange | CSDS-1J100A | CSDS-1J101A | 605 | 100 | 190 | 10 |
1.80 inch | 38*56*11 | Red | CSDS-1J100V | CSDS-1J101V | 625 | 70 | 150 | 10 |
1.80 inch | 38*56*11 | Red | CSDS-1J100L | CSDS-1J101L | 630 | 70 | 140 | 10 |
1.80 inch | 38*56*11 | Red | CSDS-1J100U | CSDS-1J101U | 645 | 40 | 100 | 10 |
